Meanwell PSPA-1000-12 Power Supply

Nguồn Meanwell PSPA-1000-12

Tính Năng:

• Universal / Full Range AC Input
• Built-in active PFC function
• Protection: Short circuit / Over load / Over voltage / Over temperature
• Forced air cooling with built-in DC fan
• With DC signal output OK
• Share current up to 4000W (3 + 1)
• Built-in remote ON-OFF control
• Integrated remote sensing function
• Fixed switching frequency at PFC: 88KHz PWM: 100KHz
• Optional altitude up to 3000 meters (Note 6)

Thông số chi tiết về sản phẩm

Model		PSPA-1000-12	PSPA-1000-15	PSPA-1000-24	PSPA-1000-48
OUPUT	DC VOLTAGE	12V	15V	24V	48V
	RATED CURRENT	80A	64A	42A	21A
	CURRENT RANGE	0 ~ 80A	0 ~ 64A	0 ~ 42A	0 ~ 21A
	RATED POWER	960W	960W	1008W	1008W
	RIPPLE & NOISE (max.) Note.2	150mVp-p	150mVp-p	200mVp-p	250mVp-p
	VOLTAGE ADJ. RANGE	11 ~ 14V	14 ~ 17V	22 ~ 28V	46~ 56V
	VOLTAGE TOLERANCE Note.3	±2.0%	±1.5%	±1.0%	±1.0%
	LINE REGULATION	±0.5%	±0.5%	±0.5%	±0.5%
	LOAD REGULATION	±2.0%	±1.5%	±0.5%	±0.5%
	SETUP, RISE TIME	1000ms, 50ms/115VAC 1000ms, 50ms/230VAC at full load
	HOLD UP TIME (Typ.)	16ms at full load
INPUT	VOLTAGE RANGE Note.4	90 ~ 264VAC(300VAC for 5 sec.) 127 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	POWER FACTOR (Typ.)	0.95/230VAC 0.99/115VAC at full load
	EFFICIENCY (Typ.)	92.00%	93%	93.50%	94.00%
	AC CURRENT (Typ.)	8.5A/115VAC 5A/230VAC
	INRUSH CURRENT (Typ.)	20A/115VAC 40A/230VAC
	LEAKAGE CURRENT	<0.5mA / 240VAC
